TASCAM’s SD-20M is a simple-to-use solid-state recorder for demanding installations. The 1U rackmount includes a pair of microphone preamps with phantom power for direct microphone recording. Both the mic inputs and line inputs can be recorded simultaneously in four-channel mode. The dual recording mode captures a copy of your audio at a lower level, as insurance against distorted takes.
The SD-20M includes a battery backup system – AA batteries can keep recording for hours in case of power loss. A wired remote or footswitch can be attached to control recording and playback. Variable speed playback allows the playback to be changed without affecting the pitch.
Designed for installations like schools, house of worship, and conferences, the TASCAM SD-20M is a flexible, affordable solution for long-form recording.
Four-track solid-state recorder
Stereo or four-track recording (two mic/line inputs + two line inputs)
Two microphone inputs on XLR-1/4" combo jacks, compatible with +4 dBu line level and switchable phantom power (+48V)
Two RCA line inputs on rear side for tracks 3-4 (compatible with -10 dBV line level)
Two recording formats supported:
Simple user interface
Low-cut filter with three levels (40/80/120 Hz)
Dual recording function records a copy of your audio at a lower level for a distortion-proof safety track
File divide feature
Variable speed playback changes speed without changing the pitch (0.5 times to 1.5 times in 0.1 increments)
Auto-recording function to automatically start recording based on input level
RCA stereo line outputs
Standard stereo headphones output
AA battery backup - keeps recording even after power loss
SDXC media slot supports cards up to 128GB
